Video means the VCA info can be displayed by any general video player.
7.2 Display Sengs
It oers the parameter sengs to adjust image features.
Go to Conguraon → Image → Display Sengs .
Click Default to restore sengs.
7.2.1 Image Adjustment (Thermal Channel)
You can opmize the image display eect of thermal channel by seng background correcon and
manual
correcon.
Background Correcon
Fully cover the lens with an object of uniform temperature in front of the lens, such as foam
board or paperboard. When you click DPC (Defecve Pixel Correcon), the device will take the
uniform object as the standard and
opmize the image once.
Manual Correcon
Click DPC (Defecve Pixel Correcon) to opmize the image once.
Note
It is a normal phenomenon that short video freezing might occur during the process of Background
Correcon and Manual Correcon.
Thermal AGC Mode
Linear mode is for scene with low temperature dierence and the target is not obvious. It can
improve image contrast and enhance image. E.g. the bird in forest.
7.2.2 Set
Palee
You can select the palee mode to display the thermal grayscale image to colored image.
Steps
1.
Go to Conguraon → Image → Display Sengs .
2.
Select a palee mode in Image Enhancement according to your need.
Result
The live view displays the image with palee.
Thermographic Cube Camera User Manual
25
