3.
Drag the corners of the area to adjust the size and shape.
Go to Live View interface to view the maximum temperature and rule of the area in thermal
channel.
3.3.5 Set Shielded Region
You can congure areas from being detected.
Steps
1.
Check Enable Shield Area.
2.
Click .
3.
Drag the mouse in the live view to draw the area. You can drag the corners of the red rectangle
area to change its shape and size.
4.
Right click the mouse to stop drawing.
5.
Oponal: Select one area and click to delete it.
6.
Click Save.
3.4 External Temperature Sensor
The device can receive the temperature and alarm informaon detected by the external
temperature sensors.
To receive data from temperature sensors, you should set:
●
Set 433 MHz Transmission
●
Connect Temperature Sensors to Device
●
Set External Temperature Sensor
3.4.1 Set 433 MHz Transmission
You can enable the 433 wireless network transmission funcon to receive and send the
thermometry informaon through the 433 module.
Steps
1.
Go to Conguraon → 433 Module Conguraon → Basic Sengs .
2.
Check Enable 433 Wireless Network Transmission.
3.
Conrm the baud rate. The xed baud rate is 10 k.
4.
Click Save.
3.4.2 Connect Temperature Sensors to Device
Before starng 433 wireless network transmission, you should congure temperature sensors, and
connect the sensors to the device.
Thermographic Cube Camera User Manual
14
