EURO 280 Installation Manual
Page: 10
2.3 Technical Specification
Programmable Outputs Ratings Normal State Active State
Output 1 Relay, 3A, max 30V Normally Closed Normally Open
Output 2 Relay, 3A, max 30V Normally Closed Normally Open
Speaker 16 ohms No tones Repeat RKP tones & internal sounder
Strobe Output 500mA 12v 0v
Bell Output 500mA 12v 0v
ATE Outputs 2mA 5v 0v
All outputs are programmed in "CHANGE OUTPUTS" in the Engineer menu.
Input Resistance 1k / 1k DEOL Range 4k7 / 2k2 DEOL Range 4k7 / 4k7 DEOL Range
Normal 0k5 to 1k4 1k4 to 2k9 3k7 to 8k3
Burglary Alarm 1k5 to 5k9 4k2 to 7k8 8k4 to 10k2
Fault 6k to 8k1 8k to 11k3 10k3 to 14k9
Masking 8k2 to 17k 11k6 to 22k 15k to 22k
Tamper <0k5 or >17k <1k4 or >22k <3k7 or >23k
All inputs are programmed in "CHANGE INPUTS" in the Engineer menu.
Fuses Value Type
Bell fuse for Bell terminals 800mA
E-fuse, resettable, non-replaceable
Inputs fuse for Input terminals 800mA
E-fuse, resettable, non-replaceable
Auxiliary fuse for Aux terminals 800mA
E-fuse, resettable, non-replaceable
RS485 Bus Fuse for bus terminals 800mA
E-fuse, resettable, non-replaceable
Battery Fuse for battery terminals 3.15A anti-surge timed blow 250V Glass
Panel Power Supply Output Nominal Range
Output Voltage 15V DC 13.5-18V DC
Output Current 2.0A Continuous 0 ~ 3.4A
Power Supply Type A.
Maximum output peak ripple voltage: Max 120mVp-p
SD Voltage which the deep discharge protection function will operate at: 10.5V
Over Voltage Protection Trigger Voltage: 18.75V ~ 21.75V
NOTE 1. EURO 280 power supplies are NOT designed for use with multiple batteries connected.
NOTE 2. System load should not exceed the panel power supply output shown above, or the maximum load supportable by the battery for the
specified backup time, as in the table shown below.
NOTE 3. The power ratings are based on battery shown in table – but ANY battery capable of supporting the system load for the required time
may be used without affecting these ratings.
Panel Power Supply Input Nominal Range
Mains Supply Voltage AC 230V AC at 50Hz -15% +10%
PSU Rating 51VA 18.5V at 2.5A
Battery Charging Specification
Float Voltage 13.8v DC Current Limit 700mA
Battery low voltage cut off 10.5v Standby battery capacity 7A to 17A
Recharge time <24 Hours
EN50131-6:2008 Rated Output
In accordance with EN50131-6:2008, the control panel standby times and effective output currents depend on the Security Grade of the
system and how 230V mains missing fault is signaled to the Alarm Receiving Centre. Power supplies are rated in accordance with the
requirements of EN50131-6, which are related to the maximum battery size that can be accommodated in the housing and vary according to
the grade of the system in which they are installed, as per the following table:
Electrical Capability EN50131-6 Rating. Maximum Load
Example Battery Model Grade 2 Grade 3
Yuasa NP7-12 1.4A 0.9A
EN50131-1:2006+A1:2009 (30 hrs if notified to an ARC) for 17Ah battery = 477mA (Grade 3).
EN50131-1:2006+A1:2009 (60 hrs if not notified to an ARC) for 17Ah battery = 193mA (Grade 3).
