EURO 280 Installation Manual
Page: 38
6.7 Connecting the Enforcer Wireless Zone Expander Module (EURO-ZEM32-WE)
EURO-ZEM32-WE
The EURO-ZEM32-WE is a wireless input
expander that supports Two Way Wireless
Enforcer technology. Each expander will allow
32 wireless inputs. The first expander on the
bus will allow 32 wireless keyfobs and 2
wireless bells.
The EURO 280 will support 3 x
EURO-ZEM32-WE
Please see page: 4.
6.7.1 EURO-ZEM32-WE Technical Specification
EURO-ZEM32-WE (Two Way Wireless Input Expander)
Input Voltage 9-14V
Current Consumption 60mA quiescent
115mA during transmission
Radio Frequency 868MHz FM Transceiver Narrow Band. Range: 300m open space
Dimensions (metal box) 173 x 125 x 32mm
Colour and Casing White plastic casing
Indication LEDs (Power and Data)
Temperature Operational: -10°C to +50°C
Certified: -10°C to +40°C
Storage: -40°C to +80°C
Humidity 85% @ 25°C
Weight 0.24kg
6.7.2 Addressing the EURO-ZEM32-WE (From the Expander)
The EURO 280 will support both wired and wireless expanders on the same bus.
Wireless sounders and keyfobs must be learned to Address 0.
NOTE: Please make sure that you address the EURO-ZEM32-WE while the tamper switch is open. The address will then
be assigned when the tamper is closed.
