EURO PCB Current Consumption Environmental
Quiescent 75-90mA Operational -10°C to +40°C, Certified
User Code and Tag Guessing Storage -20°C to +60°C
4-digit codes 10,000 Humidity 75%
6-digit codes 100,000 Dimensions
Disallowed codes None
Metal Casing
(L) 390 x 305 x 100mm
Weight: 6kg
All codes 16
12
According to EN50131-3:2009 Annex B EURO Printed Circuit Board 159 x 175 x 25mm
According to spec of manufacturer of RFID components
used
EN50131 Grading
EURO 280 Grade 3
The below table specifies ATS (Alarm Transmission System) performance criteria in accordance with the
requirements of EN50136-1.
Notification Equipment
Grade 2 Criteria
Option A Option B Option C Option D
Remotely powered external
sounder
2 Optional Optional Optional
Self-powered external sounder Optional 1 Optional Optional
Main Communication Path (ATS) ATS 2 ATS 2 ATS 2 ATS 3
Second Communication Path (ATS) Optional Optional ATS 1 Optional
Notification Equipment Grade 3 Criteria
Option A Option B Option C Option D
Remotely powered external sounder 2 Optional Optional Optional
Self-powered external sounder Optional 1 Optional Optional
Main Communication Path (ATS) ATS 4 ATS 4 ATS 4 ATS 5
Second Communication Path (ATS) Optional Optional ATS 3 Optional
When used with a supervised premises transceiver, options 'Grade 3 Option D' are supported. The use of the Digi
Modem restricts the options up to 'Grade 2 Option B'.
2.1 Important Installation Notes
Ensure wiring is done to the national wiring regulations in the country where the installation is taking place. In
the UK, this is BS 7671 Requirements for electrical installations; IET Wiring Regulations (17th edition). If in
doubt, consult a local qualified electrician.
Ensure that a readily accessible disconnect device incorporated in the premises installation wiring shall be
provided external to the equipment with a contact separation of at least 3,0mm and connected as closely as
possible to the supply. Example: Unswitched Fused Spur Unit
When fixing external wires, ensure that means are provided in the installation to prevent the SELV (Safety
Electrical Low Voltage) or signal circuits from coming into contact with live parts of the power supply circuit.
Wires shall be fixed near their terminal blocks.
The end of stranded conductor shall not be consolidated by soft soldering at places where the conductor is
subjected to contact pressure. Example: Must not solder ends of wires which are to be secured in detector and
control panel terminal connectors.
On completion of wiring use tie-wraps to prevent any loose wires causing a safety hazard (material of cables tie
shall be rated at least HB or better).
Cables ties and hoses shall be separate for power supply cable and SELV (Safety Electrical Low Voltage) wirings.
Size of protective bonding conductors: minimum section 1.5mm². Example: Electrical Earth wire connections.
