HIKVISION DS-1100KI Quick Start Guide

Figure 4-2 Device Management
2. Tap Center Device or IPC/IP Dome as desired.
3. Tap
.
4. Enter device IP address, port, user name, and password.
Note
• The device name is obtained
automacally or can be congured as required.
• If you enable the stream encrypon for the device, you need to enter the vericaon code
when adding the device.
5. Check or uncheck Add Video Recorder Output.
Note
Check Add Video Recorder Output, and the output port type, channel number and other
informaon will be listed in the output port list.
6. Tap OK.
DS-1100KI(B) Network Keyboard Quick Start Guide
5

HIKVISION DS-1100KI Specifications

General

Split keyboard	No
Keyboard layout	-
Device interface	RS-232 + RS-485 + RJ-45
Recommended usage	Office
Keyboard form factor	Mini
Connectivity technology	Wired
Display type	TFT
Product color	Black
Keyboard style	Straight
Ergonomic design	Yes
Product type	Control panel
Housing material	Plastic
Quantity per pack	1 pc(s)
USB 2.0 ports quantity	1
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Operating voltage	12 V
Power source type	DC

Weight and Dimensions

Depth	110 mm
Width	435 mm
Height	193 mm
Keyboard weight	2000 g
Keyboard dimensions (WxDxH)	435 x 110 x 193 mm
