HIKVISION DS-2CC11D3S-IR User Manual

HD-SDI Camera·User Manual
16
16
3. Fix the mounting base on the ceiling with screws.
Fix the Mounting Base Figure 2-6
Note: If required, you can route cables through the side opening on the side
of the mounting base.
Side Opening Figure 2-7
4. Loosen the tilt lock screws, adjust the tilting position in a range of 65
degrees, and tighten the tilt lock screws.
Side Opening

HIKVISION DS-2CC11D3S-IR Specifications

General

Brand	HIKVISION
Model	DS-2CC11D3S-IR
Category	Security Camera
Language	English
