HIKVISION DS-2CC11D3S-IR User Manual

HD-SDI Camera·User Manual
17
17
5. Rotate the black liner to adjust the panning position in a range of 180
degrees until you get the desired surveillance angle.
Angle Adjustment Figure 2-8
Note: As the lens has already been factory adjusted to the best imaging effect,
you just need to adjust the panning position and tilting position to get the
desired surveillance angle.
6. Reinstall the lower dome and tighten the screws.
Lower Dome Reinstallation Figure 2-9
Tilt Lock Screw
Black Liner
PAN
TILT

HIKVISION DS-2CC11D3S-IR Specifications

General

Brand	HIKVISION
Model	DS-2CC11D3S-IR
Category	Security Camera
Language	English
