Only the arrow on the B side shows. An object crossing a congured line in both direcons
can be detected and trigger alarms.
A->B
Only an object crossing the congured line from the A side to the B side can be detected.
B->A
Only an object crossing the congured line from the B side to the A side can be detected.
3) Oponal: Set Target Detecon as Human or Vehicle to discard alarms which are not triggered
by human body or vehicle.
Note
This funcon is only available for certain models.
4) Click Draw Area and draw a quadrilateral in the preview window by specifying four vertexes of
the
detecon region.
6. Set the arming schedule. Refer to Congure Arming Schedule for details.
7. Set the linkage
acons. Refer to Congure Alarm Linkage Acon for details.
8. Click Apply.
Intrusion
Detecon
Intrusion detecon funcon detects people, vehicles, or objects that enter and loiter in a pre-
dened virtual region.
Steps
1. Go to Conguraon → Event → Smart Event → Intrusion .
2. Set Camera.
3. Turn on Enable.
4.
Oponal: Check Save VCA Picture to save the captured pictures of VCA detecon.
5. Set the detecon rules and detecon areas.
1) Set Arming Area. Up to 4 arming areas are selectable.
2) Adjust Time Threshold and
Sensivity.
Sensivity
The size of the object that can trigger the alarm. The higher the value is, the more easily
the
detecon alarm will be triggered. Its range is [1-100].
Time Threshold
Range [1s-10s], the threshold for the me of the object loitering in the region. When the
duraon of the object in the dened detecon area is longer than the set me, the alarm
will be triggered.
3)
Oponal: Set Target Detecon as Human or Vehicle to discard alarms which are not triggered
by human body or vehicle.
