User Manual of DS-7200/7300/8100 Series DVR
115
2. Select to enter the Tag Playback interface.
3. Select the channels from the list, and specify the start time and end time for search.
4. Optionally, you can input the keyword of the tag name in the Keyword text field to narrow the search.
5. Click Search, and the tags matching the search conditions will be displayed on a list.
6. Click button to play back the file.
You can click the Back button to back to the search interface.
Pre-play and post-play time can be set according to actual needs.
Pre-play time and post-play time is added to the time point of the tag.
Figure 6. 12 Interface of Playback by Tag
Figure 6. 13 Toolbar of Playback by Tag
Table 6. 3 Detailed Explanation of Playback-by-tag Toolbar
