User Manual of DS-7200/7300/8100 Series DVR
212
13.2 Configuring RS-232 Serial Port
The RS-232 serial port is provided by DS-7300 and DS-8100 models only.
Purpose:
The RS-232 port can be used in two ways:
• Parameters Configuration: Connect a PC to the device through the PC serial port. Device parameters can be
configured by using software such as HyperTerminal. The serial port parameters must be the same as the device’s
when connecting with the PC serial port.
• Transparent Channel: Connect a serial device directly to the device. The serial device will be controlled remotely
by the PC through the network.
Steps:
1. Enter the RS-232 Settings interface.
Menu > Configuration > RS-232
Figure 13. 2 RS-232 Settings Interface
2. Configure RS-232 parameters, including baud rate, data bit, stop bit, parity, flow control and usage.
3. Click Apply to save the settings.
