User Manual of DS-7200/7300/8100 Series DVR
59
4.1 Configuring PTZ Settings (A)
This section is applied to the Network HDVR and Network DVR series.
Purpose:
Follow the procedure to set the parameters for PTZ. The configuring of the PTZ parameters should be done
before you control the PTZ camera.
Before you start:
For connection to the analog camera/dome, please check that the PTZ and the device are connected properly
through RS-485 interface.
Steps:
1. Enter the PTZ Settings interface.
Menu>Camera>PTZ>General
Figure 4. 1 PTZ- General
2. Choose the camera for PTZ setting in the Camera dropdown list.
3. Enter the parameters of the PTZ camera.
All the parameters should be exactly the same as the PTZ camera parameters. Only PTZ Protocol can be
set for network cameras.
Example: If the PTZ camera has a Baud rate as 115200, you should input 115200 in the Baud rate field.
4. Click Copy if you want to configure same settings to other PTZ cameras.
5. Click Apply button to save the settings.
4.2.1 Setting PTZ Presets, Patrols & Patterns
Before you start:
Please make sure that the presets, patrols and patterns should be supported by PTZ protocols.
To Next Page
