Figure 6. 15 Draw Area for Smart Search (2)
The VCA event of face detection is supported by DS-7200HWI-E1(E2)/C/F series, and the line crossing
detection and intrusion detection are supported by the smart DVR/HDVR models with no /F suffix.
4. Click and drag the mouse to draw area(s) for smart search of VCA event or motion event.
Line Crossing Detection (not for DS-7200HWI-E1(E2)/C/F)
Click the button , and click on the video display screen to specify the start point and end point of
the line.
Face Detection (for DS-7200HWI-E1(E2)/C/F only)
Click the button, and specify 4 points to set a quadrilateral region for face detection. Only one
region can be set.
Intrusion Detection (not for DS-7200HWI-E1(E2)/C/F)
Click the button, and specify 4 points to set a quadrilateral region for intrusion detection. Only one
region can be set.
Motion Detection
Click the button and then click and draw the mouse to set the detection area manually. You can also
click the button to set the full screen as the detection area.
5. Click the to search, and then the result will be displayed as in the progress bar of the Smart
Playback interface.
Or you can click the button to clear all the set areas.
6. Click the button to play
