User Manual of DS-7200/7300/8100 Series DVR
132
6. Select record files to export. You can use the following two ways to enter the Export interface.
Select motion detection event (s) from the list and click Quick Export button to enter the Export
interface, as shown in Figure 7.11.
(1) Click the Details button to enter the interface with detailed information of the record file, e.g.,
start time, end time, file size, etc.
The size of the currently selected files is displayed in the lower-left corner of the window.
(2) Select record file (s) from the list and click Export button to enter the Export interface, as
shown in Figure 7.11.
Figure 7. 10 Event Details Interface
7. Export the selected record files.
Click the Export button and start backing up.
If the inserted USB device is not recognized:
• Click the Refresh button.
• Reconnect device.
• Check for compatibility from vendor.
You can also format USB flash drive or USB HDDs via the device.
