User Manual of DS-7200/7300/8100 Series DVR
134
The eSATA writer is supported by DS-7300 and DS-8100 models only.
Steps:
1. Enter Playback interface.
Please refer to Chapter 6.
2. During playback, use buttons and in the playback toolbar to start or stop clipping record
file(s).
Figure 7. 13 Interface of Playback by Time
3. Click the icon to enter the Clips Export interface.
A maximum of 30 clips can be selected for each channel.
4. Click the button Export to export the selected video clips to the backup device.
Figure 7. 14 Export Video Clips Using USB Flash Drive
