User Manual of DS-7200/7300/8100 Series DVR
148
left. And you can set the duration for the alarm response actions, such as full screen monitoring, audible
warning, etc.
Intrusion Detection: This function can be used for detecting whether there are people, vehicles and
objects intruding into the pre-defined region longer than the set duration. And you can set the duration
for the alarm response actions, such as full screen monitoring, audible warning.
4. Check the Enable checkbox to enable the selected VCA detection.
5. Click to configure the trigger channel, arming schedule and linkage actions.
Figure 8. 17 Set Triggering Channel of VCA Alarm
1) Select Trigger Channel tab and select one or more channels which will start to record/capture or
become full-screen monitoring when a VCA alarm is triggered, and click Apply to save the
settings.
2) Select Arming Schedule tab to set the arming schedule of handling actions.
Figure 8. 18 Set Arming Schedule of VCA Alarm
Choose one day of a week, and up to 8 time periods can be set within each day. Click Apply to
save the settings.
Time periods shall not be repeated or overlapped.
Repeat the above steps to set up arming schedule of other days of a week. You can also use Copy
button to copy an arming schedule to other days.
