User Manual of DS-7200/7300/8100 Series DVR
55
Main CVBS and Spot Output 1.
The Spot Output 1 is provided for DS-7300-SH and DS-8100-SH models.
Full Screen Monitoring Dwell Time: The time in seconds to show alarm event screen.
2. Setting Camera Order
Figure 3. 10 Live View- Camera Order
To set the camera order:
1) Click the View tab to enter the camera order settings interface.
2) Select an output interface and select a screen layout.
3) Click to select a screen in the right region and double-click to select a channel in the left region.
Thus the selected channel will be displayed in the corresponding screen.
means the channel will not be displayed.
4) You can click to start live view of all channels and click to stop live view of all channels.
Click or to go to the previous or next page.
5) Click the Apply button to save the setting.
