User Manual of DS-7200/7300/8100 Series DVR
70
Calling Presets
Purpose:
The view angle of the PTZ camera will be moved to the predefined position when you call a preset.
Steps:
1. Click the button in the lower-right corner of the PTZ setting interface;
or press the PTZ button on the front panel;
or click the PTZ Control icon in the quick setting toolbar during the live view process,
or click PTZ Control on the right-click menu to open the PTZ control panel in live view mode.
2. Select the PTZ camera from the drop-down list for control.
3. Click the icon on the panel and then click the General tab to enter the general PTZ control
interface.
4. Input the preset No. in the corresponding text field, and then click the Call Preset button to call it.
Figure 4. 18 PTZ Control Panel-Call Preset
For the DS-7200HWI-E1(2)/C, DS-7300HWI-E4/C and DS-8100HWI-E4 (8)/C series, you can call the
preset 95 to enter the menu of the connected Coaxitron camera/dome. Use the directional buttons on the
PTZ control panel to operate the menu.
Customizing Patrols
Purpose:
A patrol is a scanning track specified by a group of user-defined key points, with the scanning speed between
two key points and the duration time at each key point separately programmable. The key points are
corresponding to the presets.
Steps:
1. Enter the PTZ Settings interface.
Menu > Camera > PTZ
