User Manual of DS-7200/7300/8100 Series DVR
82
Enable 960Mode: Enable the encoding at WD1 (PAL: 960×576, NTSC: 960×480) resolution for
the analog cameras. You can also uncheck the checkbox to disable it.
This feature is available for DS-7204HWI-SV, DS-7224/7232HVI-SH, DS-7200HWI-SH,
DS-7200HVI-SV, DS-7200HWI-SL, DS-7200HWI-E1(2)/C, DS-7200HWI-E1(2)/C/F,
DS-7200HWI-E1/E2; DS-7300HWI-SH, DS-7300HI-SH, DS-7300HWI-E4/C; DS-81000HWI-E4
(8) /C, DS-8100HCI-SH and DS-8100HWSI-SH models only.
5) Select the Main Stream and Substream for analog camera recording. When the substream is
selected, you can record for a longer time with the same storage space.
6) If you want to copy the current main stream settings to other analog camera (s), click Copy to
enter the Copy Camera interface. Select the analog camera (s) and click OK to finish the copy
settings.
Figure 5. 5 Copy Camera Settings
7) On the Record settings interface, click Apply to save the settings.
You can click the Restore button to restore the current main stream settings to the default parameters.
3. Set encoding parameters for sub-stream.
1) Click the Substream tab to enter the Substream settings interface.
Figure 5. 6 Encoding Parameters-Sub-stream
2) Configure the parameters for the sub-stream. Refer to the step of main stream settings.
3) Click Apply to save the settings.
You can click the Restore button to restore the current sub-stream settings to the default parameters.
4) If you want to copy the current sub-stream settings to other camera (s), click Copy to enter the
Copy Camera interface. Select the camera (s) and click OK to finish the copy settings.
