Network Video Recorder User Manual
133
6.1.9 Playing Back Pictures
The playback by picture is supported by the DS-9600/8600/7700/7600NI-I (/P) series NVR only.
Purpose:
The captured pictures stored in the HDDs of the device can be searched and viewed.
Step 1 Enter Playback interface.
Menu>Playback
Step 2 Select Picture from the drop-down list in the upper-left corner of the page to enter the
Picture Playback interface.
Step 3 Check checkbox to select the channel(s) and specify the start time and end time for
search.
Step 4 Click Search to enter Search Result interface.
Up to 4000 pictures can be displayed each time.
Step 5 Choose a picture you want to view and click button.
You can click Back to return to the search interface.
Figure 6-20 Result of Picture Playback
Step 6 The toolbar in the bottom part of Playback interface can be used to control playing process.
