Network Video Recorder User Manual
95
Pre-record: The time you set to record before the scheduled time or event. For example,
when an alarm triggers the recording at 10:00, and if you set the pre-record time as 5
seconds, the camera records at 9:59:55.
Post-record: The time you set to record after the event or the scheduled time. For
example, when an alarm triggered recording ends at 11:00, and if you set the post-record
time as 5 seconds, it records till 11:00:05.
Expired Time: The expired time is period for a recorded file to be kept in the HDD. When
the deadline is reached, the file will be deleted. If you set the expired time to 0, the file
will not be deleted. The actual keeping time for the file should be determined by the
capacity of the HDD.
Redundant Record/Capture: By enabling redundant record or capture you save the record
and captured picture in the redundant HDD. See Chapter Configuring Redundant
Recording and Capture.
Record Audio: Check the checkbox to enable or disable audio recording.
Video Stream: Main stream and sub-stream are selectable for recording. When you select
sub-stream, you can record for a longer time with the same storage space.
3) Click Apply to save the settings.
You can enable the ANR (Automatic Network Replenishment) function via the web browser
(Configuration > Storage > Schedule Settings > Advanced) to save the video files in the IP camera
when the network is disconnected, and synchronize the files to the NVR when the network is
resumed.

The redundant record/capture is used when you want to save the record files or captured
pictures in the redundant HDD. You must configure the redundant HDD in HDD settings. For
detailed information, see Chapter 14.4.2 .

The parameters of Main Stream (Event) are read-only.
Step 3 Parameters Settings for Sub-stream
1) Enter the Sub-stream tab page.

HIKVISION DS-7608NI-I2/8P Specifications

General

Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	15 W
Total Power over Ethernet (PoE) budget	120 W
Networking standards	IEEE 802.3af, IEEE 802.3at
USB 2.0 ports quantity	1
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Power over Ethernet (PoE)	Yes
Ethernet LAN (RJ-45) ports	9
Supported network protocols	TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP, HTTP, HTTPS
Power over Ethernet (PoE) ports quantity	8
Number of fans	1 fan(s)
Input bandwidth	80 Mbit/s
Number of users	64 user(s)
Output bandwidth	256 Mbit/s
Maximum resolution	3840 x 2160 pixels
Alarm input channels	4
Video input channels	8 channels
Video formats supported	H.264, H.264+, H.265, H.265+, MPEG4
Still image resolution(s)	3840 x 2160, 1920 x 1080, 1600 x 1200, 1280 x 1024, 1280 x 720, 1024 x 768
Analog signal format system	NTSC, PAL
Resolution at capture speed	1920x1080@60fps
HDD capacity	0 GB
HDD interface	Serial ATA
Maximum storage capacity	12 TB
Number of HDDs installed	0
Number of HDDs supported	2
Certification	FCC Part 15 Subpart B, ANSI C63.4-2014 CE EN 55032:2015, EN 61000-3-2, EN 61000-3-3, EN 50130-4
Product color	Black, Silver
Rack capacity	1U
Wi-Fi	No

Weight and Dimensions

Depth	315 mm
Width	385 mm
Height	52 mm
Weight	3000 g
