HIKVISION DS-7608NI-K1 User Manual

Network Video Recorder User Manual
143
Figure 7-10 Result of Event Search
Step 6 Export the video files. Please refer to step5 of Chapter 7.1.2 Backing up by Normal Video
Search for details.
7.1.4 Backing up Video Clips or Captured Playback Pictures
Purpose:
You may also select video clips or captured pictures in playback mode to export directly during
Playback, using USB devices (USB flash drives, USB HDDs, USB writer), SATA writer or eSATA HDD.
Step 1 Enter Playback interface.
Please refer to Chapter 6.1 Playing Back Record Files.
Step 2 During playback, use buttons or in the playback toolbar to start or stop clipping
record file (s); or use the button to capture pitcures.
Step 3 Click the to enter the file management interface.
Figure 7-11 Video Clips or Captured Pictures Export Interface
Step 4 Export the video clips or captured pictures in playback. Please refer to step5 of Chapter 7.1.2
Backing up by Normal Video Search for details.

HIKVISION DS-7608NI-K1 Specifications

General

Audio system	2-way
Video codecs	H.265/H.265+/H.264/H.264+/MPEG4
Input bandwidth	80 Mbit/s
Maximum resolution	1920 x 1080 pixels
Alarm input channels	4
Video input channels	8 channels
Alarm output channels	1
Supported resolutions	1920 × 1080, 1600 × 1200, 1280 × 1024, 1280 × 720, 1024 × 768
Output current	1.8 A
Output voltage	48 V
Power consumption (typical)	10 W
Total Power over Ethernet (PoE) budget	75 W
HDMI output	Yes
Networking standards	IEEE 802.3af, IEEE 802.3at
USB 2.0 ports quantity	2
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN (RJ-45) ports	9
Supported network protocols	TCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP, HTTPS
Power over Ethernet (PoE) ports quantity	8
HDD capacity	0 GB
HDD interface	SATA, SATA II, SATA III
Maximum storage capacity	6 TB
Number of HDDs installed	0
Wi-Fi	No
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Certification	EN 301489-1, EN 301489-19, EN 301489-52, EN 303413, EN 301511, EN 301908-1, EN 301908-2, EN 301908-13, EN 62311:2008
Product color	Black
Rack capacity	1U

Weight and Dimensions

Depth	240 mm
Width	315 mm
Height	48 mm
Weight	1180 g
