Network Video Recorder User Manual
212
12.4 Configuring Network Detection
Purpose:
You can obtain network connecting status of NVR through the network detection function,
including network delay, packet loss, etc.
12.4.1 Testing Network Delay and Packet Loss
Step 1 Enter the Network Traffic interface.
Menu >Maintenance>Net Detect
Step 2 Click the Network Detection tab to enter the Network Detection menu, as shown in Figure
12-26.
Figure 12-26 Network Detection Interface
Step 3 Enter the destination address in the text field of Destination Address.
Step 4 Click Test button to start testing network delay and packet loss. The testing result pops up
on the window. If the testing is failed, the error message box will pop up as well. Refer to
Figure 12-27.
Figure 12-27 Testing Result of Network Delay and Packet Loss
12.4.2 Exporting Network Packet
Purpose:
By connecting the NVR to network, the captured network data packet can be exported to USB-flash
disk, SATA/eSATA, DVD-R/W and other local backup devices.
Step 1 Enter the Network Traffic interface.
Menu >Maintenance>Net Detect
Step 2 Click the Network Detection tab to enter the Network Detection interface.
Step 3 Select the backup device from the dropdown list of Device Name, as shown in Figure 12-28.

Table of Contents

Other manuals for HIKVISION DS-7608NI-K1

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HIKVISION DS-7608NI-K1 and is the answer not in the manual?

HIKVISION DS-7608NI-K1 Specifications

General IconGeneral
Audio system2-way
Video codecsH.265/H.265+/H.264/H.264+/MPEG4
Input bandwidth80 Mbit/s
Maximum resolution1920 x 1080 pixels
Alarm input channels4
Video input channels8 channels
Alarm output channels1
Supported resolutions1920 × 1080, 1600 × 1200, 1280 × 1024, 1280 × 720, 1024 × 768
Output current1.8 A
Output voltage48 V
Power consumption (typical)10 W
Total Power over Ethernet (PoE) budget75 W
HDMI outputYes
Networking standardsIEEE 802.3af, IEEE 802.3at
USB 2.0 ports quantity2
Ethernet LAN data rates10, 100 Mbit/s
Ethernet LAN (RJ-45) ports9
Supported network protocolsTCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP, HTTPS
Power over Ethernet (PoE) ports quantity8
HDD capacity0 GB
HDD interfaceSATA, SATA II, SATA III
Maximum storage capacity6 TB
Number of HDDs installed0
Wi-FiNo
Operating temperature (T-T)-10 - 55 °C
Operating relative humidity (H-H)10 - 90 %
CertificationEN 301489-1, EN 301489-19, EN 301489-52, EN 303413, EN 301511, EN 301908-1, EN 301908-2, EN 301908-13, EN 62311:2008
Product colorBlack
Rack capacity1U
Weight and Dimensions IconWeight and Dimensions
Depth240 mm
Width315 mm
Height48 mm
Weight1180 g
