18.1.2 DS-9600NI-I16
Model
DS-9616NI-I16
DS-9632NI-I16
DS-9664NI-I16
Video/Aud
io input
IP video input
16-ch
32-ch
64-ch
Incoming
bandwidth
256 Mbps
320 Mbps
320 Mbps
Or 200 Mbps (when RAID is enabled)
Outgoing
bandwidth
256 Mbps, or 200 Mbps (when RAID is enabled)
Video/Aud
io output
VGA1 /HDMI1
output
resolution
VGA1: 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1280 ×
1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
HDMI1: 4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 2K
(2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1600 × 1200/60Hz,
1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
VGA2 /HDMI2
output
resolution
VGA2: 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 ×
720/60Hz, 1024 × 768/60Hz
HDMI2: 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 ×
720/60Hz, 1024 × 768/60Hz
Audio output
2-ch, RCA (Linear, 1 KΩ)
Decoding
Decoding format
H.265/H.265+/H.264/H.264+/MPEG4
Recording
resolution
12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA
/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
Synchronous
playback
16-ch
Capability
12-ch @ 12 MP (20fps) / 4-ch @ 8 MP (25fps) / 8-ch @ 4MP
(30fps) / 16-ch @ 1080p (30fps)
Network
managem
ent
Network
protocols
TCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP,
NFS, iSCSI, UPnP™, HTTPS
Hard disk
SATA
16 SATA interfaces
eSATA
1 eSATA interface
Capacity
Up to 6 TB capacity for each disk
Disk array
Array type
RAID 0, RAID 1, RAID 5, RAID 6, RAID 10
External
interface
Two-way audio
1-ch, RCA (2.0 Vp-p, 1 k Ω)
Network
2, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface

HIKVISION DS-7608NI-K1 Specifications

General

Audio system	2-way
Video codecs	H.265/H.265+/H.264/H.264+/MPEG4
Input bandwidth	80 Mbit/s
Maximum resolution	1920 x 1080 pixels
Alarm input channels	4
Video input channels	8 channels
Alarm output channels	1
Supported resolutions	1920 × 1080, 1600 × 1200, 1280 × 1024, 1280 × 720, 1024 × 768
Output current	1.8 A
Output voltage	48 V
Power consumption (typical)	10 W
Total Power over Ethernet (PoE) budget	75 W
HDMI output	Yes
Networking standards	IEEE 802.3af, IEEE 802.3at
USB 2.0 ports quantity	2
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN (RJ-45) ports	9
Supported network protocols	TCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP, HTTPS
Power over Ethernet (PoE) ports quantity	8
HDD capacity	0 GB
HDD interface	SATA, SATA II, SATA III
Maximum storage capacity	6 TB
Number of HDDs installed	0
Wi-Fi	No
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Certification	EN 301489-1, EN 301489-19, EN 301489-52, EN 303413, EN 301511, EN 301908-1, EN 301908-2, EN 301908-13, EN 62311:2008
Product color	Black
Rack capacity	1U

Weight and Dimensions

Depth	240 mm
Width	315 mm
Height	48 mm
Weight	1180 g
