HIKVISION DS-7608NI-K1 User Manual

Network Video Recorder User Manual
95
Pre-record: The time you set to record before the scheduled time or event. For example,
when an alarm triggers the recording at 10:00, and if you set the pre-record time as 5
seconds, the camera records at 9:59:55.
Post-record: The time you set to record after the event or the scheduled time. For
example, when an alarm triggered recording ends at 11:00, and if you set the post-record
time as 5 seconds, it records till 11:00:05.
Expired Time: The expired time is period for a recorded file to be kept in the HDD. When
the deadline is reached, the file will be deleted. If you set the expired time to 0, the file
will not be deleted. The actual keeping time for the file should be determined by the
capacity of the HDD.
Redundant Record/Capture: By enabling redundant record or capture you save the record
and captured picture in the redundant HDD. See Chapter Configuring Redundant
Recording and Capture.
Record Audio: Check the checkbox to enable or disable audio recording.
Video Stream: Main stream and sub-stream are selectable for recording. When you select
sub-stream, you can record for a longer time with the same storage space.
3) Click Apply to save the settings.
You can enable the ANR (Automatic Network Replenishment) function via the web browser
(Configuration > Storage > Schedule Settings > Advanced) to save the video files in the IP camera
when the network is disconnected, and synchronize the files to the NVR when the network is
resumed.

The redundant record/capture is used when you want to save the record files or captured
pictures in the redundant HDD. You must configure the redundant HDD in HDD settings. For
detailed information, see Chapter 14.4.2 .

The parameters of Main Stream (Event) are read-only.
Step 3 Parameters Settings for Sub-stream
1) Enter the Sub-stream tab page.

HIKVISION DS-7608NI-K1 Specifications

General

Audio system	2-way
Video codecs	H.265/H.265+/H.264/H.264+/MPEG4
Input bandwidth	80 Mbit/s
Maximum resolution	1920 x 1080 pixels
Alarm input channels	4
Video input channels	8 channels
Alarm output channels	1
Supported resolutions	1920 × 1080, 1600 × 1200, 1280 × 1024, 1280 × 720, 1024 × 768
Output current	1.8 A
Output voltage	48 V
Power consumption (typical)	10 W
Total Power over Ethernet (PoE) budget	75 W
HDMI output	Yes
Networking standards	IEEE 802.3af, IEEE 802.3at
USB 2.0 ports quantity	2
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN (RJ-45) ports	9
Supported network protocols	TCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP, HTTPS
Power over Ethernet (PoE) ports quantity	8
HDD capacity	0 GB
HDD interface	SATA, SATA II, SATA III
Maximum storage capacity	6 TB
Number of HDDs installed	0
Wi-Fi	No
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Certification	EN 301489-1, EN 301489-19, EN 301489-52, EN 303413, EN 301511, EN 301908-1, EN 301908-2, EN 301908-13, EN 62311:2008
Product color	Black
Rack capacity	1U

Weight and Dimensions

Depth	240 mm
Width	315 mm
Height	48 mm
Weight	1180 g
