HIKVISION DS-9600 Series User Manual

User Manual of DS-9600/8600/7700/7600 Series NVR
134
8.1 Setting Motion Detection Alarm
Steps:
1. Enter Motion Detection interface of Camera Management and choose a camera you want to
set up motion detection.
Menu> Camera> Motion
Figure 8. 1 Motion Detection Setup Interface
2. Set up detection area and sensitivity.
Tick “Enable Motion Detection”, use the mouse to draw detection area(s) and drag the
sensitivity bar to set sensitivity.
Click Handling button and set alarm response actions.
3. Click Trigger Channel tab and select one or more channels which will start to
record/capture or become full-screen monitoring when motion alarm is triggered.
Figure 8. 2 Set Trigger Camera of Motion Detection
