User Manual of DS-9600/8600/7700/7600 Series NVR
136
8.2 Setting Sensor Alarms
Purpose:
Set handling method of an external sensor alarm.
Steps:
1. Enter Alarm Settings of System Configuration and select an alarm input.
Menu> Configuration> Alarm
Select Alarm Input tab to enter Alarm Input Settings interface.
Figure 8. 4 Alarm Status Interface of System Configuration
2. Set up the handling method of the selected alarm input.
Check the Setting checkbox and click Handling button to set up its alarm response actions.
Figure 8. 5 Alarm Input Setup Interface
3. Select Trigger Channel tab and select one or more channels which will start to record/capture
or become full-screen monitoring when an external alarm is input.
4. Select Arming Schedule tab to set the channel’s arming schedule.
