1.2 IR Remote Control Operations
The NVR may also be controlled with the included IR remote control, shown in Figure 1. 7.
Note: Batteries (2×AAA) must be installed before operation.
Figure 1. 7 Remote Control
The keys on the remote control closely resemble the ones on the front panel. See Figure 1. 7.
Table 1. 5 Description of the Soft Keyboard Icons
No.
Name
Description
1
POWER
Power on/off the device.
2
DEV
Enables/Disables Remote Control.
3
Alphanumeric
Buttons:
Same as Alphanumeric buttons on front panel.
4
EDIT Button
Same as EDIT/IRIS+ button on front panel.
5
A Button
Same as A/FOCUS+ button on front panel.
6
REC Button
Same as REC/SHOT button on front panel.
7
PLAY Button
Same as the PLAY/AUTO button on front panel.
