HIKVISION DS-k2210 User Manual

Main Elevator Controller User Manual
88
Select the access control device from the list on the left.
Click Add button to add a new linkage. You can select the event source as Event Linkage or Card
Linkage.
Event Linkage
For the event linkage, the alarm event can be divided into four types: device event, alarm input,
door event, and card reader event.
Steps:
1. Select a device on the left and click Add.
2. Click to select the linkage type as Event Linkage, and select the event type from the dropdown
list.
 For Device Event, select the detailed event type from the dropdown list.
 For Alarm Input, select the type as alarm or alarm recovery and select the alarm input
name from the panel.
 For Door Event, select the detailed event type and select the source door from the panel.
 For Card Reader Event, select the detailed event type and select the card reader from the
panel.
3. Click different tabs to set different parameters. Switch the property from to to
enable this function.
You can set the parameters of buzzer, recording, alarm output, zone, access control point, and
audio play.
Linkage Type
Linkage Target
Descriptions
Buzzer
Host Buzzer
The audible warning of controller will be triggered.
Card Reader
Buzzing
The audible warning of card reader will be triggered.

HIKVISION DS-k2210 Specifications

General

DC input voltage	12 V
Power source type	DC
Housing color	Gray
Relay outputs	5

Weight and Dimensions

Depth	167 mm
Width	105 mm
Height	30 mm
