Main Elevator Controller User Manual
89
Recording
Capture Status
The real-time capture will be triggered.
Alarm Output
Alarm Output
The alarm output will be triggered for notification.
Access Control
Point
Access Control
Point
The door status of open, close, remain open, and
remain closed will be triggered.
Notes:
 The door status of open, close, remain open, and
remain close cannot be triggered at the same
time.
 The target door and the source door cannot be
the same one.
4. Click Save to save and take effect of the parameters.
Card Linkage
Steps:
1. Click to select the linkage type as Card Linkage.
2. Input the card No. or select the card from the dropdown list.
3. Select the card reader from the panel for triggering.
5. Click different tabs to set different parameters. Switch the property from to to
enable this function.
You can set the parameters of buzzer, recording, alarm output, zone, access control point, and
audio play.
Linkage Type
Linkage Target
Descriptions
Buzzer
Host Buzzer
The audible warning of controller will be triggered.
Card Reader
Buzzing
The audible warning of card reader will be triggered.
Recording
Capture Status
The real-time capture will be triggered.
Alarm Output
Alarm Output
The alarm output will be triggered for notification.
Access Control
Point
Access Control
Point
The door status of open, close, remain open, and
remain closed will be triggered.
Notes:
 The door status of open, close, remain open, and
remain close cannot be triggered at the same
time.
 The target door and the source door cannot be
the same one.
4. Click Save to save and take effect of the parameters.
7.10.3 Cross-Device Linkage
Purpose:

HIKVISION DS-k2210 Specifications

General

DC input voltage	12 V
Power source type	DC
Housing color	Gray
Relay outputs	5

Weight and Dimensions

Depth	167 mm
Width	105 mm
Height	30 mm
