Note
●
The suggested depth of the installaon hole is 33 mm.
●
The dimensions above are for reference only. The actual size can be slightly dierent from the
theorecal dimension.
Steps
1.
Paste the installaon Scker 1 onto the wall. Make sure the scker is placed horizontally via
measuring with the gradienter.
2.
Drill 4 holes according to the screw holes on the
scker. The suggested length of cables le
outside is 270 mm.
Figure 3-13 Drill Screw Holes
3.
Remove the scker and insert the expansion sleeves into the screw holes.
4.
Fix the mounng frame onto the wall with 4 expansion bolts.
DS-KD7003EY-IME2 Module Door Staon User Manual
18
