Figure 3-22 Connect Cables and Insert the Modules

Note

Cable 1 refers to the cables pulled out from the wall that connected to the main unit. Cable 2

refers to the module-connecng line in the accessory package.

Fix the cover with 2 socket head cap screws by using a hexagon wrench (supplied).
