Single Building Topology
Figure 4-3 Single Building Topology
Note
○
Up to 22 indoor staons with Wi-Fi or 64 without Wi-Fi can be used in one building. (The cable
needs to be beer than AWG20)
○
Up to 16 oor shunts can be cascaded.
●
Single Building (Combined)
DS-KD7003EY-IME2 Module Door Staon User Manual
43
