HIKVISION DS-KD8003 Series

No. Descripon
8 Two-Wire Interface (24 VDC Power Input)
9 Module-Connecng Interface (output)
10 Terminals
Two-Wire Main Unit (without
Buon)
Figure 1-4 Two-Wire Main Unit (without Buon) Appearance
Table 1-4 Appearance
Descripon
No. Descripon
1 Microphone
2 Low Illuminaon IR Supplement Light
3 Built-in Camera
DS-KD8003 Series Module Door Staon User Manual
6
