HIKVISION DS-KD8003 Series User Manual

No. Interface Descripon
B2 AIN1 For the access of Door Magnec 1
B3 AIN3 For the access of Exit Buon 1
B4 AIN4 For the access of Exit Buon 2
B5 485- Module-connecng Interface
B6 485+
B7 12 V OUT2
B8 GND
C LAN PoE Network Interface(Supports IEEE 802.3af)
Table 3-2 Power Supply
Power Supply Door Staon Power Output
PoE (802.3af) DC 12V OUT1/DC 12V OUT2
6 W MAX in total
DC 12 V DC 12V OUT2
18 W MAX
Two-Wire Main Unit Terminal
Figure 3-2 Two-Wire Main Unit Terminal
DS-KD8003 Series Module Door Staon User Manual
11
