HIKVISION DS-KD8003 Series User Manual

Figure 6-9 Audio Sengs
2.
Congure the stream type and the audio encoding type.
Audio Channel
Select the audio channel to adjust the audio parameters.
Stream Type
Select the stream type to main stream or sub stream.
Audio Encoding
The device support G.711ulaw and G.711 alaw.
3.
Adjust the Input Volume, Output Volume and Speak Volume.
Note
Available range of volume: 0 to 10.
4.
Click Save to save the sengs.
DS-KD8003 Series Module Door Staon User Manual
87

HIKVISION DS-KD8003 Series Specifications

General

Ingress Protection	IP65
Operation System	Embedded Linux
Camera	2MP
Video Compression Standard	H.264
Resolution	1920 x 1080
Video Input	1 channel
Video Output	1 channel
Audio Input	Built-in microphone
Audio Output	Built-in speaker
Audio Compression Standard	G.711
Audio Compression Rate	64 Kbps
Ethernet	10/100 Mbps
Network Protocol	TCP/IP
RS-485	1 channel
Alarm Input	1 channel
Debug Port	1 channel
TF Card	Support up to 128GB
Installation	Wall-mounted
Power Supply	12 VDC
Working Humidity	10% to 90% (No Condensation)
Network Interface	RJ45
Working Voltage	12 VDC
