HIKVISION Network Audio/Video Encoder User Manual

User Manual of DS-6700 Series Audio/Video Encoder
51
7.3.15 Configuring Multicast Address
Purpose:
The multicast address can be configured to realize live view for more than the maximum number of cameras
through network.
A multicast address spans the Class-D IP range of 224.0.0.0 to 239.255.255.255. It is recommended to use the IP
address ranging from 239.252.0.0 to 239.255.255.255.
Steps:
1. Click Remote Configuration > Network Settings > Advanced to enter the multicast address settings
interface.
Figure 7.32 Multicast Address Settings
2. Enter the multicast address in the text filed.
3. Click Save to save the settings.
