2. Description
T–shaped transportation handle, pull-out type
Folding transportation handle
Transportation or lifting lever for raising the wheels
Lifting points for transportation by crane
Cable and hose storage compartment
400 V electric cables for drive motors
24 V electric cable for control system
2 compressed air connections for advance pressure
cylinder
1 water connection, water supply from construction site
2 water connections for cooling water supply to the
diamond wire
2 baseplates for securing the drive unit to the floor
or ground
Three-point supports, adjustable in height
