HIMA HIMatrix F2 DO 16 01

F2 DO 16 01 3 Product Description
HI 800 159 E Rev. 2.00 Page 15 of 40
3.4 Assembly
This chapter describes the layout and function of the remote I/Os, and their communication via
safeethernet.
DO
16 01
2
Figure 3: Front View
DO 1
DO 16
1
2
3
4
RJ-45
RJ-45
16 Digital Outputs
Safety-Related Processor System (CPU)
Switch
Watchdog
Figure 4: Block Diagram
