HIMA HIMatrix F2 DO 16 01 User Manual

3 Product Description F2 DO 16 01
Page 16 of 40 HI 800 159 E Rev. 2.00
3.4.1 LED Indicators
The light-emitting diodes (LEDs) indicate the operating state of the remote I/O. The LEDs are
classified as follows:
 Operating voltage LED
 System LEDs
 Communication LEDs
 I/O LEDs
3.4.1.1 Operating Voltage LED
LED Color Status Description
On 24 VDC operating voltage present 24 VDC Green
Off No operating voltage
Table 5: Operating Voltage LED
3.4.1.2 System LEDs
While the system is being booted, all LEDs are lit simultaneously.
LED Color Status Description
On Device in RUN, normal operation
Blinking Device in STOP
A new operating system is being loaded.
RUN Green
Off The device is not in the RUN state.
On The device is in the ERROR STOP state.
Internal fault detected by self-tests, e.g., hardware faults or cycle time
overrun.
The processor system can only be restarted with a command from the
PADT (reboot).
Blinking
If ERROR blinks and all others LEDs are lit simultaneously, the boot
loader has detected an operating system fault in the flash memory and
waits for a new operating system to be loaded.
ERROR Red
Off No faults detected.
On A new configuration is being loaded into the device.
Blinking The device switches from INIT to STOP
A new operating system is being loaded into the flash ROM.
PROG Yellow
Off No configuration or operating system is being loaded.
FORCE Yellow Off
The FORCE LED of a remote I/O is not functioning. The FORCE LED of
the associated controller serves to signal the forcing of a remote I/O.
On The loaded configuration is not valid.
The new operating system is corrupted (after OS download).
Blinking Fault while loading a new operating system
One or multiple I/O faults occurred.
FAULT Yellow
Off None of the described faults occurred.
Blinking Operating system emergency loader active. OSL Yellow
Off Operating system emergency loader inactive.
Blinking OS and OSL binary defective or hardware fault, INIT_FAIL. BL Yellow
Off None of the described faults occurred.
Table 6: System LEDs
