F2 DO 16 01 3 Product Description
HI 800 159 E Rev. 2.00 Page 21 of 40
3.5.1 Product Data F2 DO 16 014
The F2 DO 16 014 model variant is intended for use in railway applications. The electronic
components are coated with a protective lacquer.
F2 DO 16 014
Operating temperature -25…+70 °C
Output current of the digital
outputs
max. 2 A at < 40 °C
max. 1 A at 40…60 °C
max. 0.5 A at > 60 °C
Weight approx. 0.9 kg
Table 13: Product Data F2 DO 16 014
The remote I/O F2 DO 16 014 meets the conditions for vibrations and shock test according to
IEC 61373, category 1, class B.
3.6 Certified HIMatrix F2 DO 16 01
HIMatrix F2 DO 16 01
CE EMC, ATEX Zone 2
TÜV IEC 61508 1-7:2000 up to SIL 3
IEC 61511:2004
EN ISO 13849-1:2008 up to Cat. 4 und PL e
UL Underwriters Laboratories
Inc.
ANSI/UL 508, NFPA 70 – Industrial Control Equipment
CSA C22.2 No.142
UL 1998 Software Programmable Components
NFPA 79 Electrical Standard for Industrial Machinery
IEC 61508
FM Approvals Class I, DIV 2, Groups A, B, C and D
Class 3600, 1998
Class 3611, 1999
Class 3810, 1989
Including Supplement #1, 1995
CSA C22.2 No. 142
CSA C22.2 No. 213
TÜV CENELEC Railway applications
EN 50126: 1999 up to SIL 4
EN 50128: 2001 up to SIL 4
EN 50129: 2003 up to SIL 4
Table 14: Certified HIMatrix F2 DO 16 01
