HIMA HIMatrix F2 DO 16 01

4 Start-up F2 DO 16 01
Page 26 of 40 HI 800 159 E Rev. 2.00
4.3.2.1 Tab Module
The Module tab contains the following system parameters:
System parameter
Data
type
R/W Description
DO.Error Code WORD R Error codes for all digital outputs
Coding Description
0x0001 Fault within the digital outputs
0x0002 Test of safety shutdown returns a fault
0x0004 Test of auxiliary voltage returns a fault
0x0008 FTT test of test pattern faulty
0x0010 Output switch test pattern faulty
0x0020
Output switch test pattern (shutdown test of the
outputs) faulty
0x0040 Active shutdown via WD faulty
0x0100
Outputs 1...4 and 9...12 de-energized due to
total current overrun
0x0200
Outputs 5...8 and 13...16 de-energized due to
total current overrun
0x0400 FTT test: 1st temperature threshold exceeded
0x0800 FTT test: 2nd temperature threshold exceeded
0x1000
FTT test: Monitoring of auxiliary voltage 1:
Undervoltage
0x2000
FTT test: Monitoring of auxiliary voltage 2:
Undervoltage
Module Error Code WORD R Module error code
Coding Description
0x0000
I/O processing, if required with errors, see
other error codes
0x0001 No I/O processing (remote I/O not in RUN)
0x0002 No I/O processing during the booting test
0x0004 Manufacturer interface operating
0x0010 No I/O processing: invalid configuration
0x0020 No I/O processing: fault rate exceeded
0x0040/
0x0080
No I/O processing: configured module not
plugged in
Module SRS UDINT R Slot number (System Rack Slot)
Module Type UINT R Type of module, target value: 0x005A [90
dec
]
Table 19: SILworX - System Parameters for Digital Outputs, Module Tab
