F2 DO 16 01 4 Start-up
HI 800 159 E Rev. 2.00 Page 27 of 40
4.3.2.2 Tab DO 16: Channels
The DO 16: Channels tab contains the following system parameters.
System
parameter
Data
type
R/W Description
Channel no. --- R Channel number, defined by default
-> Error Code
[BYTE]
BYTE R Error codes for the digital output channels
Coding Description
0x01 Fault in the digital output module
0x02 Channel shutdown due to overload
0x04 Error while reading back the control signal
0x08
Error while reading back the status of the digital
outputs
Value [BOOL]
->
BOOL W Output value for DO channels:
1 = output energized
0 = output de-energized
Table 20: SILworX - System Parameters for Digital Outputs, DO 16: Channels Tab
4.4 Configuration with ELOP II Factory
4.4.1 Configuring the Outputs
The signals previously defined in the Signal Editor (Hardware Management) are assigned to the
individual channels (outputs) using ELOP II Factory. Refer to the system manual for compact
systems or the online help for more details.
The following chapter describes the system signals used for assigning signals in the remote I/O.
4.4.2 Signals and Error Codes for the Output
The following tables specify the system signals that can be read and set for the outputs,
including the corresponding error codes.
In the user program, the error codes can be read using the signals assigned within the logic.
The error codes can also be displayed in ELOP II Factory.
