Hioki 3284 - Page 95

5
―――――――――――――――――――――――――――
Chapter 1 Product Outline
――――――――――――――――――――――――
DC V AC+DC V
A
CV
⑥
SLOW/PEAK/Hz
･ SLOW slows down screen updating (once per three
seconds).
･ FAST speeds up screen updating (four times per
second). There isn't an annunciator "
FAST
".
Instead, the unit symbol blinks.
･ PEAK measures peak values (Peak Hold).
･ Hz measures frequency (in AC or AC+DC mode).
⑦
･ Switches voltage modes as follows.
⑧
MAX/MIN
･ Displays the maximum value (MAX), the minimum
value (MIN), or the average value (AVE) of the
maximum and minimum values for the recording
(REC) function.
･ MAX displays the maximum measured value after
the REC function is activated.
･ MIN displays the minimum measured value after the
REC function is activated.
･ AVE displays the average value of the maximum
and minimum measured values after the REC
function is activated.
･ The auto power-off function is disabled in the REC
function.
