6
―――――――――――――――――――――――――――
Chapter 1 Product Outline
――――――――――――――――――――――――
⑨
0ADJ/RESET
･ Performs auto-zero-adjustment in DC A, AC+DC A
and DC V modes.
･ Resets data when measuring peak values. Reset all
the data in a REC function.
･ If zero is not indicated under no input in the AC A,
AC+DC A, AC V or AC+DC V modes, press
HOLD
, then press
0ADJ/RESET
to perform a zero-
cancel correction.
⑩ Clamp sensor
･ To measure current, open the top ends of the clamp
sensor by gripping the lever ⑪ . Then position the
conductor to be measured at the center of the clamp
sensor and firmly close the clamp sensor.
⑪ Lever
･ Used to open and close the clamp sensor.
