6.3 Printing
95
6
Chapter 6 Printing
Example Printouts______________________________________________
Statistical Calculations (Comparator ON)
*** RESISTANCE ***
Number 85
Valid 85
Average 13.06mOhm
Max 13.78mOhm( 74)
Min 12.10mOhm( 3)
Sn 0.38mOhm
Sn-1 0.38mOhm
Cp 1.32
CpK 0.09
Comp Hi 40
Comp IN 45
Comp Lo 0
*** VOLTAGE ***
Number 85
Valid 85
Average 10.0074 V
Max 10.0197 V ( 57)
Min 9.9938 V ( 31)
Sn 0.0068 V
Sn-1 0.0068 V
Cp 0.35
CpK 0.32
Comp Hi 10
Comp IN 59
Comp Lo 16
Measurement values
(V mode)
100 3.70079 V
101 -58.3306 V
102 203.086 V
Measurement values
(
V mode)
1 2.5375mOhm, 4.70056 V
2 - 0.9730mOhm, 4.70055 V
3 15.142mOhm,-0.00002 V
4 160.68mOhm, 267.031 V
5 15.039 Ohm,- 50.254 V
6 200.12 Ohm, 11.3176 V
7 2.9984kOhm,-11.3099 V
8 0.1615 Ohm,-4.70054 V
9 0.166 Ohm,- 4.7006 V
10 0.16 Ohm,- 4.700 V
Measurement values
( mode)
43 17.855mOhm
44 0.641 Ohm
45 1.9984kOhm
With erroneous measurement values
90 O.F. ,-4.70053 V
91 1.0647 Ohm, O.F.
92 O.F. , O.F.
93 - O.F. , 4.70051 V
94 -------- ,--------
95 Invalid , Invalid
With the Comparator ON
50 5.033 Ohm Hi, 1.60427 V IN
51 5.033 Ohm Hi,-0.00001 V Lo
52 17.855mOhm IN
53 18.354mOhm Hi
54 15.322mOhm Lo
55 4.70072 V IN
56 -4.70070 V Lo
With comparator reference percentages
3120 28.653 % Hi, 0.111 % Hi
3121 - 0.192 % Lo,- 0.001 % IN
3122 O.F. Hi, 0.317 % Hi
Interval print
00:00:00 16.020mOhm, 3.70052 V
00:00:01 16.015mOhm, 3.70052 V
00:00:02 16.010mOhm, 3.70052 V
00:00:03 16.006mOhm, 3.70051 V
00:00:04 16.002mOhm, 3.70052 V
00:00:05 15.999mOhm, 3.70051 V
00:00:06 15.998mOhm, 3.70051 V
Max/Min count
Measurement values indicated as "Invalid" cannot be displayed by the instru-
ment.
The number of statistical calculation results indicated as “Valid” equals the
count of valid data excluding measurement faults and overflows.
