8.6 Message Reference
161
8
Chapter 8 RS-232C/GP-IB/LAN Interfaces
Compatibility of each of the Model 3560 commands is described below with details of the functional differ-
ences with this instrument.
For the Model BT3560, the command header is set to OFF when the instrument is turned on or reset
(including *RST).
Message ([ ] = optional) Data Contents
( ) = response data
Differences
Model BT3562 (BT3562-01) Model 3560
Standard Commands
IDN?
<Manufacturer's
name>,<Model name>,0,
<Software version>
Model name in response data:
BT3561A
BT3562A
BT3562
BT3562-01
BT3563A
BT3563
BT3563-01
Model name in response data:
3560
OPC
OPC?
1
RST
Initialization contents
Measurement mode:
V mode (Resistance and
voltage measurement)
Header: OFF
(Model BT3562)
Power supply frequency: AUTO
Zero-adjust value: Initialized to 0
(Model 3560)
Power supply frequency: 50 Hz
Zero-adjust value: Not initialized
Initialization contents
Measurement mode: Resis-
tance measurement mode
Header: ON
SRE
SRE?
0 to 255 (NR1)
STB?
0 to 255 (NR1)
TRG
TST?
0 to 3 (NR1) Response data
bit2: -, bit1: EEP-ROM,
bit0: RAM
Response data
bit2: EEP-ROM, bit1: RAM,
bit0: ROM
WAI
Device-Specific Commands
:MODe
:MODe?
R/ RV
:RRANge
:RRANge?
0 to 3.1E+3
3E-3 to 3E+3
:VRANge
:VRANge?
-300 to 300
6E+0/60E+0/100E+0/
300E+0
Voltage range: -300 to 300
6 V, 60 V, 100 V
*1,
and 300 V
*2
ranges are supported.
*1: The 100 V range is only
available on the Model
BT3562A.
*2: The 300 V range is only
available on the Model
BT3563A, BT3563, or
BT3563-01.
Voltage range: -50 to 50
Response: 5E+0/ 50E+0
:AUTorange
:AUTorange?
1/ 0/ ON/ OFF
ON/ OFF
Setting is not possible when the
comparator is enabled (when
the comparator is set to ON,
auto-ranging is turned OFF).
Setting is possible even when
the comparator is enabled
(ON).
