4.1 Comparator Function
48
4
Select the voltage measurement range (for this example, the 6 V range).
5
The Comparator setting display appears.
6
Set the comparator judgment beeper (for this example, select IN).
oFF........no beeps sound
HL..........beeps repeatedly (when measurements are Hi or Lo)
in ...........beeps continuously (when measurements are IN)
btH1.......beeps continuously while measurements are within the thresholds (IN), and
beeps repeatedly when measurements are Hi or Lo.
btH2.......beeps once when measurements move into the threshold range (IN), and beeps
repeatedly when measurements go Hi or Lo.
7
Press so that the indicated position blinks, and select the comparator execution
mode (for this example, Auto).
A............ Auto Comparator (default setting)
E ............ Manual Comparator
V lit
oFF flashing
in flashing
A flashing
