5.4 Internal Circuitry
89
5
Chapter 5 External Control (EXT I/O)
Output Circuit
Connection Examples
BT3562,BT3563
BT3562,BT3563
BT3562,BT3563
BT3562,BT3563
BT3562,BT3563
BT3562,BT3563
Output
ISO_COM
50mA max
30 V max
Output
ISO_COM
Output
ISO_COM
Output
ISO_COM
Output
ISO_COM
Active-Low
Logic Output
Input
Common
PLC
Output
Output
ISO_COM
Input
Common
PLC
Relay Connections
LED Connection
Active-Low Logic Output
PLC Input (Source Input) Connections
PLC Input (Sink Input) Connections
Wired OR
Instruments
Instruments
Instruments
Instruments
Instruments
Instruments
