16
Parts Names and Functions
Rear and Sides
Serial number label
Please do not remove the label
as it is needed for product control
such as product warranty etc.
(The serial number consists of 9
digits. The rst two (from the left)
indicate the year of manufacture,
and the next two indicate the
month of manufacture)
Battery cover
Removed when replacing the
batteries. (p. 25)
Battery cover (side view)
Waterproof seal
It needs to be replaced when
degraded.
Please contact your authorized
Hioki distributor.
Operation Buttons
1
2
3
4
6
7
5
To Next Page
